FT-6101
VISUAL FAULT LOCATOR (1mW)

  • Laser diode design with high concentration and long test distance (3~5km)

  • Efficient conduction test

  • Constant brightness and flash, 2 section operation. Constant brightness mode: stable display of fiber conduction status. Flash mode:  quickly detect the position of fiber break point.

  • 3 types of suitable fiber optic adapters FC/SC/ST, which support2. 5mm fiber optic connectors such as FC/SC/ST
  • Overall length: 180 x 30mm

  • Wavelength : 605nm±10nm

  • Power outpu t : 1mW

  • The level of laser light : CLASS III

  • Distance test : 3~5Km

  • Battery : AAx 2
  • Applicable connectors : 2.5mm FC/ST/SCUniversal connector

  • Overall length : 180 x 30mm

  • Operating temperature : -100~+500 C

  • Storage temperature : -200~+600 C

  • Weight : 46g
