FT-6105
FIBER OPTICAL LASER  SOURCE
  • Designed for fiber optic cabling, fiber optic maintenance, acceptance, and inspection
  • Support optical wavelength: 1310nm/1550nm
  • Highly stable light source output and accurate measurement
  • Large LCD panel display with clear value. Backlit display
  • Match the same ID function optical power meter (FT-6106). The power meter automatically converts the same source wavelength
  • Source wavelength 270Hz, 1KHz, or 2KHz. Three frequencies can be selected
  • The meter provides a charger port for rechargeable batteries
  • Automatically activate hibernate mode after unused for 10 minutes
  • The product contains a case for better carrying and storage
  • Dimensions: 140 (height) x 62 (width) x 32 (depth)

  • Wavelength output(nm) :1310/1550
  • Power output: > -6dBm
  • Spectral width:10 nm
  • Stability:short time 0.03dB/ long time 0.2dB
  • Type of laser:Semiconductor laser
  • Fiber optic adapter:PC/PC
  • Carrier wave:270Hz/1KHz/2KHz
  • Automatic shutdown:have
  • Type of battery:2 AA alkaline batteries or 2 rechargeable batteries
  • Battery life:>40H
  • Waterproof:Water repellent
  • Operating temperature:-10℃~+60℃
  • Storage temperature:-20℃~+70℃
  • Relative humidity:90% Anti-condensation
  • Appearance :140 x 62 x 32 mm
  • Weight:174g
