SP-4106 <sup>5 IN 1 PROFESSIONAL MULTI-FUNCTION PLIERS</sup> - Top Forza Electronics Technology CO.,LTD

SP-4106

^{5 IN 1 PROFESSIONAL MULTI-FUNCTION PLIERS}

Taiwan R&D and manufacturing, stable and reliable quality
S50C steel forging process. The handle is made of bicolor PP & TPR material, which is non-slip, comfortable, and durable.
Multi-functional design: stripping, shearing, crimping, and hanging.
CNC precise milling machine processing. 30AWG stripping has no damage to the core.
The shear range up to ø5.5mm copper wire, and crimping non-insulated Y.O terminal to 5.5mm
Effortless spring design
Wide range of applications, such as hydropower maintenance, circuit maintenance, stripping renovation, electronic maintenance, etc.

Applied field：
non-insulated terminal
AWG:22-18/16-14/12-10 / JIS:1.25/2.0/3.5-5.5mm²
insulated terminal
AWG:22-14/28-24mm² / JIS:1.25/2.0/0.3-0.5mm²
Range of wire stripping：AWG30-10 (0.05-5.5mm²)
Shear capacity : soft iron wire Ø1.0mm / copper wire Ø2.0mm
Range of shear：AWG30-10 (0.05-5.5mm²)
Material：S50C
Length ：176 mm
